Blackmagic PYXIS Monitor Kit
The Blackmagic Design PYXIS Monitor Kit delivers a broadcast‑grade, high‑brightness touchscreen display combined with precision mounting hardware, transforming your PYXIS or URSA Cine camera into a fully extended viewfinder and control station. Built around a rugged metal chassis, the kit integrates seamlessly into any professional rig — whether shoulder‑mounted, gimbal‑stabilized, or studio‑racked—ensuring durable performance in demanding production environments.
At its core is a full‑HD 5" capacitive LCD touchscreen with 1920 x 1080 resolution and 1500 nit HDR brightness, providing crystal‑clear monitoring even in direct sunlight. The high‑pixel‑density panel supports false color, focus assist, screen markers, and zebra overlays, while a bright tally light keeps you aware of record status from any angle. A clip‑on sunshade further enhances screen visibility and reduces glare on bright sets.
Touchscreen controls grant on‑screen access to every camera function—frame rate, shutter angle, iris, ISO, white balance, tint, timecode, record start/stop, media playback, audio levels, focus zoom, digital slate, and full camera menus. Three customizable function buttons let you toggle critical tools like clean feeds, display LUTs, frame guides, safe area markers, false color, and more with a single tap, streamlining your workflow and speeding up setup.
Mounting versatility comes from multiple ARRI anti‑twist 1/4"‑20 and M4 mounting points on both the bottom and side of the monitor. The kit includes a swivel mount, fixed mount (with screws), and dovetail shoe, allowing quick transitions between camera top‑mount, side‑mount, or off‑camera configurations. A locking USB‑C viewfinder cable carries video, power, and camera control over a single connection, eliminating clutter and ensuring a solid link.
Built for 24/7 reliability, the monitor is powered entirely over USB‑C via its locking connector or external power sources, and runs on macOS (Ventura, Sonoma) or Windows 10/11 with the free Blackmagic software. It thrives in temperatures from 0°C to 40°C with up to 90% non‑condensing humidity, and includes a welcome wallet with QR code for software downloads plus a one‑year limited manufacturer’s warranty — everything you need for professional HDR monitoring and camera control.
