YoloLiv YoloBox Ultra
The YoloLiv YoloBox Ultra is the ultimate all-in-one live streaming and switching solution, combining multi-camera encoding, real-time switching, recording, and high-brightness monitoring into a single, handheld device. Its expansive 8" capacitive touchscreen delivers 650 nits of brightness for crystal-clear visibility in any environment, whether you’re on a sunlit stage or a dimly lit studio. With a Qualcomm Snapdragon CPU 865 under the hood, the Ultra delivers up to 2.5x the processing power and 4x the GPU performance of its predecessors, ensuring smooth, glitch-free streams even at UHD 4Kp60.
Video inputs are vast and versatile: connect up to four HDMI 4Kp60 cameras, one USB-C source, and three simultaneous IP feeds via NDI | HX3 or SRT, while built-in HEVC (H.265) encoding slashes bandwidth by over 50% without sacrificing image quality. Whether you’re capturing DSLR footage, game console output, or remote mobile guests, the YoloBox Ultra ingests every feed and makes it instantly available for your production workflow. A dedicated HDMI output lets you route your program to external monitors or recorders with zero delay.
Streaming connectivity is rock-solid thanks to dual-band Wi-Fi 6, gigabit Ethernet, and built-in 4G LTE cellular bonding across up to five networks. RTMP, RTMPS, SRT, and NDI | HX3 protocols are all supported, so you can broadcast simultaneously to Facebook Live, YouTube, Twitch, LinkedIn, Instagram, TikTok, and custom RTMP destinations. On-screen presets and an intuitive menu system let you configure up to three simultaneous stream targets in either horizontal or vertical orientation, maximizing your reach across social and professional platforms.
The integrated switcher puts professional multi-camera control at your fingertips: choose from picture-in-picture, side-by-side, split-view, news layouts, and triple frames, or let Auto-Switching handle source rotations automatically. Visual overlays—including custom lower thirds, countdown timers, logos, and real-time comment feeds—are managed directly from the touch interface or via third-party apps that you can install on the Ultra. Built-in chroma key allows you to superimpose talent over virtual backgrounds without external keyers.
Recording functions are equally robust: capture your switch output and each ISO source simultaneously in MP4 up to 4K, storing files to SD card or external SSD via USB-A. Adjustable resolution, frame rate, and bitrate controls let you optimize files for post-production or archival. ISO Recording support for HDMI, USB, NDI®, and SRT inputs preserves every angle, ensuring no moment is lost.
Audio is fully integrated with dual 3.5mm mic/line inputs, Bluetooth audio support, and a built-in mixer for balancing embedded HDMI sound and external sources. On-screen level meters and headphone monitoring ensure broadcast-quality audio, while advanced features like Video Follows Audio (VFA) automatically switch camera angles based on who’s speaking—perfect for solo podcasters and panel discussions.
Powering the YoloBox Ultra is a 75.48 Wh internal battery, giving you up to six hours of continuous operation. USB-C PD compatibility allows hot-swap charging from power banks or camera batteries, and a quick-release design means you never have to end a session early. Rugged mounting points and a weather-resistant chassis ensure that whether you’re on the move or in the field, your live production never stops.
