Standards |
SD Format Support
625/25 PAL and 525/29.97 NTSC.
HD Format Support
1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60.
1080PsF23.98, 24, 25, 29.97, 30.
1080i50, 59.94, 60.
720p23.98, 24, 25, 29.97, 30, 50, 59.94, 60.
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 310M, SMPTE 425M-A, SMPTE 425M-B, ITU-R BT.656 and
ITU-R BT.601. |
2K Format Support
2048 x 1556p23.98, 24, 25.
SDI Video rates
SDI video connections are switchable between standard definition, high definition and 2K. SDI switches between 270 Mb/s standard definition SDI, 1.5 Gb/s HD-SDI and 3 Gb/s HD and 2K SDI.
SDI Video Sampling
4:2:2 and 4:4:4
SDI Color Precision
4:2:2 and 4:4:4 10 bit. |
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24-bit.
SDI Color Space
YUV or RGB.
SDI Auto Switching
Automatically selects between SD-SDI, HD-SDI, 3G-SDI and DVB-ASI on each input so that each input can be running a different television standard.
SDI Metadata Support
Video payload identification ancillary data as per SMPTE 352M. |
