Blackmagic PYXIS 12K (PL Mount)
The Blackmagic Design PYXIS 12K PL is a revolutionary large‑format digital film camera engineered for cinematic capture with unmatched image quality. At its core lies a massive 36 × 24 mm RGBW sensor, delivering native 12,288 × 8,040 resolution across the full frame. Housed in a rugged yet modular box design, the camera accepts industry‑standard ARRI PL lenses and offers an open‑gate capture mode that preserves the entire sensor area for maximum creative flexibility.
With an expansive 16‑stop dynamic range and dual‑native ISO up to 25,600, the PYXIS 12K PL excels in any lighting scenario—from shooting sunlit exteriors to dim interiors—while minimizing noise and preserving highlight and shadow detail. Dual‑native ISO switching ensures optimal signal‑to‑noise performance whether you’re capturing fast‑paced action at 60 fps or creeping through low‑light environments at high frame rates.
Flexible film formats and high‑frame‑rate options make this camera a powerhouse on set. Capture full 12K at up to 40 fps in 3:2 open‑gate, anamorphic 2.4:1 at 60 fps, or unleash high‑speed 8K up to 112 fps—all selectable via a dedicated HFR button. A Super 35‑sized window lets you switch to tighter framing without cropping the sensor, perfect for run‑and‑gun workflows or rapid focal length changes.
Recording is seamless and future‑proof: dual CFexpress Type‑B card slots plus a USB‑C expansion port support Blackmagic RAW for full‑fidelity masters and simultaneous H.264 proxy recording for quick turnaround. Metadata tagging—including lens data and frame guides—flows directly into DaVinci Resolve and other NLEs, streamlining post‑production and accelerating edit-ready workflows.
Onboard monitoring and control center around a bright 4″ HDR‑capable touchscreen LCD rated at 1,500 nits. Focus peaking, zebras, histograms, wavescopes, and custom 3D LUT overlays ensure precise exposure and color while three customizable function buttons and a tactile scroll wheel let operators adjust iris, shutter, ISO, and white balance on the fly. Multiple ¼″‑20 and 3/8″‑16 mounting threads across the chassis allow attachment of handles, grips, or external recorders for a tailored rig.
Connectivity is comprehensive: a locking USB‑C port delivers power, viewfinder output, and data; a 12G‑SDI output feeds secondary monitors; a 10 GbE RJ45 port supports direct SRT/RTMP streaming and Blackmagic Cloud uploads; mini XLR audio input with phantom power and headphone jack ensure professional sound; and reference/timecode BNC ports keep multi‑camera shoots in perfect sync. Powered via Sony BP‑U batteries or 12V DC, the camera operates from 0°C to 40°C (32°F–104°F) at up to 90% non‑condensing humidity, making it a turnkey solution for next‑generation 12K cinematography.
The Blackmagic PYXIS 12K PL is backed by a one‑year limited manufacturer’s warranty, it ships with DaVinci Resolve Studio activation, power supply, caps, mounting plates — everything you need for next‑generation 12K cinematography.
